upFront.eZine 1,089: A Contractor’s View of BIM (part i)
Guest Editorial by Matt Stachoni
The Business of CAD | 29 March 2021
I recently had the vice president of a large construction company tell me he thought that BIM was “generally a nice idea, but a waste of money and resources.”
At first, I was taken aback by his assertion, but after analyzing the current state of BIM on building sides, I realized that he’s absolutely correct.
It got me thinking how BIM directly and, perhaps more importantly, indirectly benefits the construction process. Understanding how BIM is currently used in construction reveals how often its practice is antithetical to producing beneficial outcomes.
For many construction firms, massive changes in thinking are required to properly implement BIM across projects of all types before real-world results are aligned properly to BIM’s potential and promise. As a side effect, proper implementation promotes BIM as a core component essential to every project at the very outset, where such consideration has the most impact and value.
The fact is that the way most contractors typically utilize BIM on today’s construction projects is downright idiotic and costly. The problems are deeply rooted on traditional shop drawing production and coordination efforts, and fails to take into account what BIM brings to the table.
I have identified four areas where BIM usually falls flat in practice; what gets in the way of realizing many of its benefits; and an outline of a relatively simple solution. But first, some background on how construction sites work.
How Construction Teams Work
To begin, I’d like to describe some background points to explain how building construction is carried out. This may be useful to those unfamiliar with how the sausage is made.
A general contractor (GC) is hired by the owner to build the project. The GC’s primary role is split between managing the owner’s requirements and expectations, and steering the project’s workforce through the entire process.
The GC’s office team is composed of a small army of project engineers responsible for directing the trade subcontractors and supporting field operations. They do this through holding daily meetings; processing submittals; writing, routing, and tracking Requests for Information (RFIs) and the answers to and from the design team; denying change order requests; checking the quality of the work done in the field; and so on.
The GC necessarily works with the architect and engineer of record to some degree. Every project larger than a doghouse will at some point have some contract issues to deal with. So how the GC interacts with the design team depends largely on the project delivery method around which the project is based. These are:
Design-Bid-Build Method. The GC starts work from a (more or less) complete set of finished construction documents, typically interfacing with the design team’s construction administration (CA) representative, who monitors the process and handles constructability issues.
Design-Build and Integrated Project Delivery (IPD) Methods. The GC partners with the design team, as well as the subcontractors from the outset, directing everyone from start to finish and continually working out construct ability issues throughout the building phase.
The Purpose of BIM on Construction Sites
Regardless of the project delivery method, BIM quickly becomes a center of attention, because on the construction site BIM at its core does one thing and only one thing only: It answers questions. That’s a hugely powerful tool to have.
Armed with a set of high-quality construction models, a fully BIM-enabled project engineer can answer almost any question anyone has about the project.
I can tell my wall framers to the millimeter exactly where on the slab the outside corner of the wall stud should be.
I can tell the mason where a 4” chilled water pipe sleeve -- whose size properly accounts for the insulation -- needs to be placed in a CMU [concrete masonry unit] wall, appropriately accounting for the bond beam above.
We can have the surveyors precisely locate every hanger insert installed in the concrete slab, before it is placed.
We can provide fully coordinated locations, sizes, quantities, and costs of all required access panels for hidden equipment, valves, conduit pull boxes, and other maintainable items installed above hard ceilings and behind walls throughout the project.
Used in conjunction with continual laser scanning of the job site, we can tell our plumbing subcontractor how off the mark their piping stub-up is, which is popping up out of the dirt in an empty area but intended to be centered within a 6” stud wall cavity at some future point. Or where we can core drill through a concrete wall to miss the rebar, which eliminates the cost of having a specialty subcontractor come in later to scan for it using ground penetrating radar.
- - -
Sophisticated owners of large-scale facilities are getting in on the BIM action. They are demanding that the models include additional information which locates and identifies the building’s maintainable assets and so allow the Facilities Management (FM) group to extract Enterprise Asset Management (EAM) information automatically and drop it into their FM operations databases.
Of course, that kind of wow factor doesn’t come cheap or easy. However, the benefits are exponentially greater than the costs, and have proved ultimately invaluable to projects at large.
This then brings me to the four primary issues I have with BIM as typically implemented on the job site.
Issue 1: Getting BIM Into the Right Hands
To review conditions and answer questions, it does no good to have this deep project knowledge silo’ed away with one or two specialized people. In many construction firms, there is a dearth of BIM expertise among project engineers. But once superintendents or project managers get a whiff of what BIM can do for them, the demand on the few who can access models is overwhelming.
While every project needs a BIM manager to control the models and ensure they are accurate and available, every project engineer and superintendent needs training and hardware to interact with the construction models using the appropriate software. This can be Revit, Navisworks, Tekla, AutoCAD, Revizto, and so on.
Issue 2: Design Intent Models are Stupid
There are crucial distinctions between models produced by a design team and the kinds of models useful to construction teams. They serve two masters and so have different requirements.
Models produced by the design team are considered an Instrument of Service. They more accurately are termed “design intent models.” They are created solely to produce code-compliant Construction Documents, which are signed and sealed by the A/E [architect or engineer] and issued for permitting.
Modeling requirements for design intent are lower than that required for actually building projects. They do not have the appropriate level of 3D detail, nor are they accompanied by the correct manufacturer-specific non-geometric information needed to answer questions we need in the field. Indeed, unless there is a constructability review, most sets of CDs do not need any proof of buildability to pass muster.
I don’t think it’s a stretch to state that most designers may understand design but not necessarily construction. They do not possess practical construction experience. Construction teams see evidence of this in almost every set of design drawings, such as overly complicated and expensive details, impractical placements of components and room types, and contradictory information.
With regards to BIM, designers often leave out of the model things that taken care of in the details with simple 2D linework. That may be fine for their intended purpose. However, missing 3D content can easily end up being critical to the coordination and constructability of the design.
HVAC engineers competently design air systems that produce 200cfm [cubic feet per minute air flow] at a specific diffuser, but the mechanical piping may use fittings that are impossible for the size of pipe, or be routed through such tight spacing that it cannot be welded or installed by hand in the field. The structural designer may leave out supplemental steel or connection modeling that impacts the pathways of MEP [mechanical, electrical, and plumbing] services.
Typically, a designer says that such problems are means and methods issues, and so are the responsibility of the trade contractors. The trades then counter that they are forced to massively re-route their work, which is a design issue. Both are right, and both are wrong. The problem remains that the design intent cannot be built.
Design-intent models do not typically reflect what is ultimately going to be purchased, fabricated, and installed in the field. These occur only once the design is completed and the trades get their hands on the CDs. Nearly every item placed on a project requires a formal submittal provided by the trade subcontractor and approved by the design team. The submittal is the combination of what is dictated in the specifications and drawings, and takes into account the subcontractor’s understanding of and familiarity with the product, its pricing, availability, and other factors – information designers simply don’t need to consider during the design phase.
Issue 3: Working with Trade Subcontractor Models
Once the design CDs are issued and the GC and trades mobilize to build, the next round of BIM-based idiocy begins -- with the trade subcontractors.
Next week: Part ii
[Matt Stachoni is a BIM Manager/Senior Project Engineer with Tutor Perini/ Parsons JV, and works on very large design-build construction projects that rely on regular IFC model exchanges to owners.]
